Tuesday, September 27, 2016

Light Cone Animation

I generated this animation of Past and Future Light Cones of a stationary point object with vertical line as it's world line using Mathematica. As such the each light cone should sweep a (pencil-like cylendrical) shape as time passes, but I am showing the light cones at any given moment only. Also the cones extend to + ve and -ve infinite time as such.



The vertical axis is time axis with unit t seconds.
The z=0 is the NOW plane showing two (not three) dimensional space. The normalized unit for space axes is ct, where c is the speed of light. Thus distance of 1 in x or y direction is the distance travelled by light in 1 second.
That gives us 45 degree sloped light cones.
The downward moving planes are future moments, becoming NOW and then the past moments.
The top cone is the Future cone.
The bottom cone is past cone.
The vertical line is the world line of a stationary point object.

Sunday, September 25, 2016

Mathematica


I started playing with Mathematica this weekend. Here is a simple widget to plot Cos and Sin functions on Unit circle. You may have to force evaluate the cell by clicking on Gear > Evaluate Cell.

Saturday, August 20, 2016

Console magic

You can detect duplicate ids by evaluating this Javascript expresssion in Chrome devtools console:

([].slice.call(document.querySelectorAll("[id]")))
    .map(function(ele){ return ele.id;})
    .sort()
    .reduce(function(countMap, word) {countMap[word] = ++countMap[word] || 1;return countMap}, {})

Boom! You will get:

> Object {
   id1: 1,
   id2: 1,
   some-other-id: 1,
   duplicate-id: 2
   …
}

What is going on here:

  • document.querySelectorAll() returns the NodeList of elements that have id attribute
  • slice() - converts a NodeList to a JavaScript Array
  • map() - converts elements array to array of id strings
  • sort() - sorts the array. If you evaluate only up to here you will get the sorted list of ids (with duplicates)
  • reduce() - creates an object with id value as key and number of occurrences as value

Additionally, if you add Object.keys(resultFromAbove).sort() you will get a sorted list of unique ids.

Also an example of Map-Reduce

BTW you can use similar, slightly modified selector expression to list the CSS classes that are used on the page and also mow many times.

Monday, August 15, 2016

Appear on hover

Recently I needed a way to have controls for resizing appear on hover using pure CSS. I wanted allow progressive discovery of the feature to collapse the panels but did not want have a clutter of controls. I also wanted that once the user learns about the new feature they can directly access it by moving their mouse there and clicking.

I did it using :nth-child(1), :nth-child(2), and :hover pseudo classes. For the pair on left hand side, the key idea is that, I had to use display:inline-block; on the container span and float: left; style on :nth-child(2)to get around the CSS limitation of not being able to use a following sibling in markup order to affect the style of preceding sibling.

Do you have better suggestions?

Saturday, August 13, 2016

A simple gradle plugin to print the task execution graph of a gradle build.

Here is a gist for a simple gradle plugin implementation that can generate an HTML report of your gradle build's Task Execution Graph.

Here is a sample output for a simple project:

↦ :clean - Deletes the build directory.
↦ :build - Assembles and tests this project.
   ┖ :assemble - Assembles the outputs of this project.
      ┖ :jar - Assembles a jar archive containing the main classes.
         ┖ :classes - Assembles main classes.
            ┖ :compileJava - Compiles main Java source. ⊣
            ┖ :processResources - Processes main resources. ⊣
   ┖ :check - Runs all checks.
      ┖ :test - Runs the unit tests.
         ┖ :classes - Assembles main classes. ↑
         ┖ :testClasses - Assembles test classes.
            ┖ :compileTestJava - Compiles test Java source.
               ┖ :classes - Assembles main classes. ↑
            ┖ :processTestResources - Processes test resources. ⊣

To use it simply apply it in your build.gradle like so:

:
:
apply from: 'build-task-graph.gradle'
:
:

And then run any build like this;

> .\gradlew -m clean build

and find the output report in:

build/reports/printteg.html


It should be a simple exercise to generate hyperlinked output or alternatively emit a .dot file graph or even generate SVG.

I use this to determine which tasks I should exclude using the -x flag and only (carefully) run the ones I need. Of course you have to know what you are doing. The idea is similar to my Maven Phases and Goals plugin.

Feedback welcome!

Tuesday, August 09, 2016

Angular 2 - template reference variable shadows the component property

Given the Angular 2 component:

import { Component } from '@angular/core';

@Component({
  moduleId: module.id,
  selector: 'app-root',
  template: '<div ref-title>{{title}}</div>',
  styleUrls: ['app.component.css']
})
export class AppComponent {
  title =  'app works!';
}

you get this on the webpage:

[object HTMLDivElement]

The reason is that Template Reference Variable ref-title shadows the title of  AppComponent when evaluating {{title}}.

I guess this is sort of like the loop variables inside an

<li *ngFor="let title in titles">{{title}}</li>

But something does not feel right about TRV.

Sunday, August 07, 2016

A simple Weather App using Angular 2, Angular Material 2 and Electron

Working on a simple Weather App using

Also runs as a standard web app.

Built using



Will document the details soon!



Sunday, June 05, 2016

Weekend Hack

I recently acquired a tripod with Bluetooth remote for my smart phone. The tripod  is only up to 10 inches tall and works very well indoors when you have something to perch it on.


However I wanted to a taller, up to 5 feet tall monopod, which I can use to video record my son's outdoor or theater concerts. I hacked it with some material that I could find in the garage:

  • L bracket as the base
  • conduit clip and knob to hold the PVC pipe


  • PVC pipe
  • velcro to firmly hold the tripod



Here is the result



Do you have any hacking ideas you would like to share?

Thursday, June 02, 2016

Try this repeatedly in your browser console...

var party = Math.random(), country = Math.random(), what = (party >= country ? 64783292855 : 2569542479746150); 'party=' + party + ' country = ' + country + ' party/county = ' + what.toString(36);

Friday, May 06, 2016

Try this in your browser console...

var party = 64783292855, country = 1; alert((party/country).toString(36));

Thinking.oO { Party/Country != Patriotism , Party/Country == Treason }

var party = 0;
var country = 1;
var result = [ 'Treason', 'Patriotism' ];

party/county =

Monday, April 25, 2016

Electronic eyes


Electronic eyes

Fun!

Sunday, April 24, 2016

Electron based POM360


A simple POM360 tool to get a 360 view of Maven POM. It is developed using Electron framework. It uses mvn command.

Saturday, April 23, 2016

Electron based Portmon tool


A simple Portmon tool to monitor listening TCP ports and associated PIDs. It is developed using Electron framework. It uses netstat.

NOTE: Works on windows only at the moment.
